LR-Cal LTC-DB-9030-35
LR-Cal LTC-DB-9030-35
Sku: LR-CAL-LTC-DB-9030-35
Temperature calibration microbath up to 250°C with ±0.2°C accuracy and ±0.03°C stability. Ideal for calibrating thermometers and temperature sensors.
Product Information
The LR-Cal LTC-DB-9030-35 dry block temperature calibrator functions as both a temperature source and reference instrument in one, designed for the testing and calibration of all types of temperature measuring devices.
- Temperature range: -30 to +150°C
- Homogeneous temperature distribution
- Simple operation via colour touchscreen
- Ramp function and thermostat testing
- Computer-controlled calibrations via USB interface and optional LR-Cal Aq2Sp2 software for MS Windows® PCs
- Wide range of interchangeable inserts with various bore sizes for different test probes
- Optional: Insert with “black body” for the calibration of infrared thermometers
- Portable metal dry block temperature calibrator
- Range -30…+150°C
- Accuracy ±0.15°C, stability ±0.03°C
- Dry block: 35 mm diameter
Immersion depth: 130 mm
| Description: | Data: | |
|---|---|---|
| Temperature range: | -30…+150°C | |
| Display: | Touchscreen (color) | |
| Display accuracy: | ±0.15°C full temperature range * | |
| Units of measure: | °C / °F / K | |
| Display resolution: | 0,1° / 0,01° / 0,00^° | |
| Mean heating time: (incl. stabilization) |
approx. 28 min. from +20°C to +140°C |
|
| Mean cooling time: (incl. stabilization) |
approx. 23 min. from +20°C to -25°C |
|
| Stability: | ±0.03°C ** | |
| Axial uniformity: | ±0.01°C | |
| Hole (block) diameter: | 35 mm | |
| Hole (block) depth: | 135 mm | |
| Insert material: | anticorodal | |
| Switch test; voltage: | Open/Closed; 4,5 VDC | |
| Adjustable ramp function: | from 0.1°C/min | |
| PC interface: | USB type B | |
| Automatic calibration: | at 5 temperature points | |
| External probes: | Optional: Order-Code LTC-MP-3I (to be ordered together with device) | |
| Operating voltage: | 230 VAC (optional 115 VAC) 50/60 Hz | |
| Electric power: | 350 W | |
| Dimensions: | 160 x 350 x 360 mm | |
| Weight incl. std. accessories: | 9.3 kg | |
All values have been measured at ambient temperature of +20°C.
The achievement of stabilization is confirmed by a displayed root symbol and an audial beep.
* = Temperature deviation between display and reference probe.
** = Max. temperature difference at stable temperature over 30 min.
*** = Measured from the button up to 60 mm.
