Keller Series 7LD
Product Information
The pressure transmitters of the 7LD series use the chip-in-oil technology developed by KELLER, uniting a pressure measuring cell, digital temperature compensation and signal processing in a compact housing made of stainless steel or Hastelloy. The transmitters are extremely resistant to environmental influences and delivery highly accurate measurement results as a digital output signal. The I2C interface and the low supply voltages make it easy to integrate in microcontroller-based systems. The extremely low power consumption is ideal for battery-operated devices. The D line is perfect for IoT solutions.
-
Ultra low power consumption, optimised for battery-powered application
-
Hermetically protected sensor electronics – extremely resistant to environmental influences
-
Ultra-compact, robust housing made from stainless steel (optional Hastelloy C-276)
-
No external electronics for compensation or signal processing
-
Extremely accurate, outstanding long-term stability, no hysteresis
-
Pressure ranges of 1 bar to 1000 bar
-
Easy to integrate into microcontroller-based systems
-
Internal two-chip solution with pressure sensor and signal processing separation provides a high degree of flexibility
Sketch
| Pressure Ranges | 0…3 to 0…200 bar |
| Accuracy | ±0,15 %FS |
| Total Error Band | ±0,7 %FS @ -10…80 °C |
| Interfaces | I2C |
| Dimensions | ? 15 mm x 5 mm |
